Nov132017 by raycombdNo Comments

TC-NC27VX

ipc
Features • Super Starlight Ultra Low Light 0.0008lux • Up To 1080P, 1920×1080@60fps • H.265/H.264 HP/MP/BP/M-JPEG Codec • Min. Illumination Color: 0.0008 Lux,B/W: 0.0001 Lux, 0 Lux with IR • Mechanical WDR 140dB • Support ABF function(Auto Back Focus) • NIR, WDR, 3D DNR, HLC, Dual-ICR, AWB, AGC, BLC • VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Face Detection/People Counting/Audio Abnormal Detection/Video Abnormal Detection/On duty Detection • Interface 2ch 100/1000M RJ45(Support 2 IP Address),Audio I/O:1/1,Alarm I/O:2/1,2ch Micro SD card slot up to 512G, Micro USB,Reset Button,BNC,USB Storage up to 128G,Power Button,ABF Button • TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V) • Operating Conditions  -35℃～65℃, 0～95% RHG • CE, FCC Specifications Camera Image Sensor 1/1.8" CMOS Core Processor ARM9 Architecture Operating System Embedded LINUX Signal System PAL/NTSC Mini. Illumination Color: 0.0008 Lux @(F1.2, AGC…
Read More
Nov132017 by raycombdNo Comments
TC-NC214

TC-NC214

ipc
Features • Up to 1920X1080@30fps • Cable Free Design • H.264/M-JPEG Codec • Min. Illumination Color: 0.5 Lux,B/W: 0.25Lux,0 Lux with IR • Smart IR, IR Range: 25m • VCA Tripwire/Perimeter • Interface MicroSD Card Slot, up to 128GB, Reset Button • TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP67 • Operating Conditions  -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG • Case Material Metal • CE, FCC Specifications Camera Image Sensor 1/2.7" CMOS Core Processor ARM9 Architecture Operating System Embedded Linux Signal System PAL/NTSC Min. Illumination Color: 0.5 Lux @(F1.2, AGC ON) B/W: 0.25Lux @(F1.2, AGC ON); 0 Lux with IR Shutter Time 1s to 1/100,000s Lens 4mm, Angle of View: 86.5° Lens Mount φ12 Auto Iris N/A Day& Night IR Cut Filter with Auto Switch Wide Dynamic Range 100…
Read More
Nov132017 by raycombdNo Comments
TC-NC44M

TC-NC44M

ipc
Features • Up To 2560X1440@25fps • H.265/H.264 HP/MP/BP/M-JPEG Codec • Min. Illumination Color: 0.05 Lux,B/W:  0.01Lux,0 Lux with IR • Motorized 2.8-12mm • Mechanical WDR 120dB • Smart IR, IR Range: 30m • VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection • Interface Audio I/O:1/1,Alarm I/O:2/1,Bulit-in Mic,Micro SD card slot up to 128G,USB,Reset Button,BNC • TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP66,IK10 • Operating Conditions  -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG • CE, FCC Specifications Camera Image Sensor 1/3"  CMOS Core Processor ARM9 Architecture Operating System Embedded Linux Signal System PAL/NTSC Min. Illumination Color: 0.05 Lux @(F1.4, AGC ON) B/W: 0.01Lux @(F1.4, AGC ON); 0 Lux with IR Shutter Time 1s to 1/100,000s Lens Motorized 2.8-12mm, Angle of View: 90.8°～32.1° Lens Mount φ14 Auto Iris DC Drive Adjustment…
Read More
Nov132017 by raycombdNo Comments
TC-NC43M

TC-NC43M

ipc
Features • Up To 2560X1440@25fps • H.265/H.264 HP/MP/BP/M-JPEG Codec • Min. Illumination Color: 0.05 Lux,B/W:  0.01Lux,0 Lux with IR • Motorized 2.8-12mm • Mechanical WDR 120dB • Smart IR, IR Range: 50m • VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection • Interface Audio I/O:1/1,Alarm I/O:2/1,Bulit-in Mic,Micro SD card slot up to 128G,USB,Reset Button,BNC • TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP67 • Operating Conditions  -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG • CE, FCC Specifications Camera Image Sensor 1/3"  CMOS Core Processor ARM9 Architecture Operating System Embedded Linux Signal System PAL/NTSC Min. Illumination Color: 0.05 Lux @(F1.4, AGC ON) B/W: 0.01Lux @(F1.4, AGC ON); 0 Lux with IR Shutter Time 1s to 1/100,000s Lens Motorized 2.8-12mm, Angle of View: 90.8°～32.1° Lens Mount φ14 Auto Iris DC Drive Day&…
Read More
Nov132017 by raycombdNo Comments
TC-NC24MS

TC-NC24MS

ipc
Features • Starlight Ultra Low Light 0.002lux • Up To 1080P, 1920×1080@30fps • H.265/H.264 HP/MP/BP/M-JPEG Codec • Min. Illumination Color: 0.002 Lux,B/W:  0.001Lux,0 Lux with IR • Motorized 2.8-12mm • Mechanical WDR 140dB • Smart IR, IR Range: 30m • VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection • Interface Audio I/O:1/1,Alarm I/O:2/1,Bulit-in Mic,Micro SD card slot up to 128G,USB,Reset Button,BNC • TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP66, IK10 • Operating Conditions  -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG • CE, FCC Specifications Camera Image Sensor 1/2.8" CMOS Core Processor ARM9 Architecture Operating System Embedded Linux Signal System PAL/NTSC Min. Illumination Color: 0.002Lux(F1.2,AGC ON) B/W: 0.001Lux(F1.2,AGC ON);0 Lux with IR Shutter Time 1s to 1/100,000s Lens Motorized 2.8-12mm, Angle of View: 92°～38.6° Lens Mount φ14 Auto Iris DC…
Read More
Nov132017 by raycombdNo Comments
TC-NC23MX

TC-NC23MX

ipc
Features • Super Starlight Ultra Low Light 0.0008lux • Up To 1080P, 1920×1080@60fps • H.265/H.264 HP/MP/BP/M-JPEG Codec • Min. Illumination Color: 0.0008 Lux,B/W: 0.0001 Lux, 0 Lux with IR • Motorized 3.6-10mm • Mechanical WDR 140dB • Smart IR, IR Range: 50m • VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection/Face Detection/People Counting/On duty Detection • Interface Audio I/O:1/1,Alarm I/O:2/1,Micro SD card slot up to 128G,USB,Reset Button,BNC,USB Storage up to 128G • TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP67 • Operating Conditions  -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG • CE, FCC Specifications Camera Image Sensor 1/1.8" CMOS Core Processor ARM9 Architecture Operating System Embedded Linux Signal System PAL/NTSC Min. Illumination Color: 0.0008 Lux @(F1.2, AGC ON) B/W: 0.0001Lux @(F1.2, AGC ON); 0 Lux with IR Shutter Time 1s…
Read More
Nov132017 by raycombdNo Comments

TC-NC23MS

ipc
Features • Starlight Ultra Low Light 0.002lux • Up To 1080P, 1920×1080@30fps • H.265/H.264 HP/MP/BP/M-JPEG Codec • Min. Illumination Color: 0.002 Lux,B/W: 0.001 Lux, 0 Lux with IR • Motorized 2.8-12mm • Mechanical WDR 140dB • Smart IR, IR Range: 50m • VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection • Interface Audio I/O:1/1,Alarm I/O:2/1,Micro SD card slot up to 128G,USB,Reset Button,BNC • TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP67 • Operating Conditions  -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG • CE, FCC Specifications Camera Image Sensor 1/2.8" CMOS Core Processor ARM9 Architecture Operating System Embedded Linux Signal System PAL/NTSC Min. Illumination Color: 0.002Lux(F1.2,AGC ON) B/W:  0.001Lux(F1.2,AGC ON); 0 Lux with IR Shutter Time 1s to 1/100,000s Lens Motorized 2.8-12mm, Angle of View: 92°～38.6° Lens Mount φ14 Auto Iris…
Read More
Nov132017 by raycombdNo Comments
TC-NC2AS

TC-NC2AS

ipc
Features • Starlight Ultra Low Light 0.002lux • Up To 1080P, 1920×1080@30fps • H.265/H.264 HP/MP/BP/M-JPEG Codec • Min. Illumination Color: 0.002 Lux,B/W: 0.001 Lux, 0 Lux with IR • Mechanical WDR 140dB • Smart IR,  IR Range: 100m • Focal Length 4.7mm～94mm • Optical Zoom: 20x, Digital Zoom: 16x • VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection • NIR, WDR, 3D DNR, HLC, Dual-ICR, AWB, AGC, BLC • Interface Audio in/out 1/1,Alarm in/out 3/2,MicroSD Card Slot, up to 128GB, Reset Button,BNC,RS-485 • TVS 6000V, Lightning/Surge 4000V Protection, IP66 • Operating Conditions -40°C-70°C, 0～95% RHG • CE, FCC Specifications Camera Image Sensor 1/2.8" CMOS Core Processor ARM7 Architecture Operating System Embedded Linux Signal System PAL/NTSC Min. Illumination Color: 0.002Lux @(F1.6, 50 IRE, ICR OFF) B/W: 0.001 Lux @(F1.6,  50 IRE,…
Read More
Nov132017 by raycombdNo Comments
TC-NC1261

TC-NC1261

ipc
Features • 12MP 360° Panoramic View • 1/1.7″ 12MP CMOS • Up To 4000 × 3072@20fps • Up To 14 Live View Display Modes • H.265/H.264 HP/MP/BP/M-JPEG Codec • VCA Tripwire/Double Tripwire/Perimeter/Early Warning/Heat Map/Audio Abnormal Detection/Video Abnormal Detection/Autotracking • Min. Illumination Color: 0.01 Lux,B/W: 0.005 Lux, 0 Lux with IR • Up to 15m IR Range • 3pcs White Light, Up to 10m Light Range • Interface Built-in Dual Mic,Built-in Speaker,Audio in/out 1/1,Alarm in/out 2/1,MicroSD Card Slot, up to 128GB, Reset • TVS 6000V, Lightning/Surge Protection: (Power 2000V,RJ45 1000V),IP66,IK10 • Operating Conditions  -30℃～60℃, 0～95% RHG • CE, FCC Specifications Camera Image Sensor 1/1.7" 12MP CMOS Core Processor A7+A17 Dual Core Processor Operating System Embedded Linux Signal System PAL/NTSC Min. Illumination Color: 0.01 Lux @(F1.2, AGC ON) B/W: 0.005Lux @(F1.2, AGC…
Read More
Nov132017 by raycombdNo Comments
TC-NC452

TC-NC452

ipc
Features • Up to 2560×1440@25fps • Cable Free Design • H.265/H.264 HP/MP/BP/M-JPEG Codec • Min. Illumination Color: 0.05 Lux,B/W: 0.01 Lux, 0 Lux with IR • IE,Chrome,Firefox, Safari, Plug-in Free • Mechanical WDR 120dB • Smart IR, IR Range: 20m • VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object • Interface Bulit-in Mic,Audio in/out 1/0,MicroSD Card Slot, up to 128GB, Reset Button • TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP67 • Operating Conditions  -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG • Case Material Metal • CE, FCC Specifications Camera Image Sensor 1/3" CMOS Core Processor ARM7 Architecture Operating System Embedded Linux Signal System PAL/NTSC Min. Illumination Color: 0.05 Lux @(F1.2, AGC ON) B/W: 0.01Lux @(F1.2, AGC ON); 0 Lux with IR Shutter Time 1s～1/100000s Lens 2.8mm, Angle of View: 99° Lens Mount φ12…
Read More
