| Camera | |
| Image Sensor | 1/2.7″ CMOS |
| Core Processor | ARM9 Architecture |
| Operating System | Embedded Linux |
| Signal System | PAL/NTSC |
| Min. Illumination | Color: 0.02Lux |
| B/W: 0.01Lux | |
| Shutter Time | 1s to 1/100,000s |
| Lens | 4mm |
| Auto Iris | N/A |
| Wide Dynamic Range | Y |
| Digital Noise Reduction | 3D DNR |
| Compression Standard | |
| Video Compression | H.264/M-JPEG |
| Video Bit Rate | 32Kbps~8Mbps |
| Image | |
| Max. Image Resolution | 1920×1080 |
| Frame Rate | PAL:1080p@15fps; NTSC:1080P@15FPS |
| couple Stream | Mainstream:1080P(1920*1080) |
| Substream:D1(704*576) | |
| Image Settings | Brightness, Saturation, Contrast,Flip Mode Adjustable by Client Software or Web Browser |
| HLC | Y |
| Smart Defog | Y |
| OSD | 16×16, 32×32, 24×24, 48×48, 64×64, 96×96 Size Letters Such as Week, Date, Time, Total 1 Regions |
| Network | |
| Browser | built-in web server |
| NTP | Y |
| Alarm Trigger | Motion Detection/IP Conflict/MAC Conflict/Port Alarm/Mask Alarm |
| Protocols | TCP/UDP/HTTP/MULTICAST/UPnP/DHCP/DDNS/FTP/NTP/RTSP/SMTP |
| User Permission | 4 Level/8 Users |
| System Compatibility | ONVIF (Profile S) |
| Interface | |
| Audio Input | N/A |
| Audio Output | N/A |
| Communication Interface | 1-ch RJ45 10M / 100M Ethernet Interface |
| Alarm Input | N/A |
| Alarm Output | N/A |
| Video Output | N/A |
| General | |
| Language | English,Simplified Chinese |
| Operating Conditions | -30℃～60℃, 0～95% RHG |
| Power Supply | DC 12 V ± 20%, POE |
| Power Consumption | Max. 3.5W(IR OFF) (ICR Instant Switch 5.5W) |
| Impact Protection | IP66 |
| IR Range | 20m |
| Dimensions | 145.5mm（longth）×82mm（width）×81mm（height） |
| Weight | 0.5KG |
