Features

• Starlight Ultra Low Light 0.002lux

• Up To 1080P, 1920×1080@30fps

• Cable Free Design

• H.265/H.264 HP/MP/BP/M-JPEG Codec

• Min. Illumination Color: 0.002 Lux,B/W: 0.001 Lux, 0 Lux with IR

• VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection

• Smart IR, IR Range: 15m

• Support Wifi

• Interface Bulit-in Mic,Audio in/out 1/1,Alarm in/out 1/1,MicroSD Card Slot, up to 128GB, Reset Button

• TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V),IK10

• Operating Conditions  -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG

• CE, FCC

Specifications

Camera
Image Sensor 1/2.8″ CMOS
Core Processor ARM9 Architecture
Operating System Embedded Linux
Signal System PAL/NTSC
Min. Illumination Color: 0.002 Lux @(F1.2, AGC ON)
B/W: 0.001Lux @(F1.2, AGC ON); 0 Lux with IR
Shutter Time 1s～1/100000s
Lens 2.8mm/4mm, Angle of View: 113.5°/83.3°
Lens Mount φ12
Auto Iris N/A
Day& Night Dual IR Cut Filter with Auto Switch
Wide Dynamic Range 140 dB
Digital Noise Reduction 3D DNR
S/N Ratio >60dB
Compression Standard
Video Compression S+265/H.265/H.264H/H.264M/H.264B/MJPEG
Video Bit Rate 32Kbps~16Mbps
Audio Compression G.711A/G.711U/ADPCM/AAC
Audio Bit Rate G711 8KHz, 64kbps
ADPCM 8KHz, 32kbps
ADPCM 8KHz, 32kbps
Max. Image Resolution 1920×1080
Frame Rate 50Hz: 25fps (1920×1080), 25fps (1280 × 960), 50fps (1280 × 720)
60Hz: 30fps (1920×1080), 30fps (1280 × 960), 60fps (1280 × 720)
Triple Stream Mainstream:1080P(1920×1080)
Substream:D1(704×576)
3rd stream:720P(1280×720)
Image Settings Brightness, Saturation, Contrast, Sharpness, Image Enhancement
,Flip Mode
HLC Y
Smart Defog Y
Corridor Y, Available for 720P and Above
EIS Y
ROI 4 Zones
Privacy Mask 4 Zones
Picture Overlay 200 × 200, BMP 24bit, Zone Configurable
OSD 16×16, 32×32, 24×24, 48×48, 64×64, 96×96 Size Letters
 Such as Week, Date, Time, Total 5 Regions
Network
Browser IE8 and above ,Firefox24 and above
Network Storage FTP
NTP Y
ANR Y, Auto store video in SD card when NVR disconnected, and upload
video to NVR when resumed connection(Only Support Tiandy ANR
NVR)
Video Analytics Tripwire/Double Tripwire/Perimeter/Object Abandon/Object
Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/
Video Abnormal Detection
Alarm Trigger Motion Detection/IP Conflict/MAC Conflict/Port Alarm/Mask Alarm
Protocols IPv4/IPv6/HTTP/802.1x/FTP/SMTP/UPnP/SNMP
DNS/DDNS/NTP/RTSP/TCP/UDP/DHCP/PPPoE
HTTPS/ARP/RTP/QoS/BONJOUR/MULITCAST/ICMP/IGMP
User Permission 4 Level/8 Users
Remote Connection 5 Users Access at the Same Time
System Compatibility ONVIF (Profile S),  SDK,CGI
Interface
Audio Input 1-ch, Bulit-in Mic
Audio Output 1-ch
Communication Interface 1-ch RJ45 10M/100M Ethernet Interface
Wifi (IEEE 802.11b/g/n)
Alarm Input 1-ch
Alarm Output 1-ch
Video Output N/A
On-board Storage MicroSD Slot, Up to 128GB
Reset Button Y
Extension N/A
General
Language English,Spanish,Korean,Italian,Turkish,Thai,Russian,
Traditional Chinese,Simplified Chinese,Polish,French
Operating Conditions  -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG
Power Supply DC12 V ± 10%, PoE (802.3af)
Power Consumption Max. 5W(IR OFF) (ICR Instant Switch 10W)
Max. 8W(IR ON)
Circuit Protection TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V)
Impact Protection Only for Indoor Installation, IK10
IR Range 15m
IR LEDs 10pcs φ3 IR LEDs
Dimensions 116mm×116mm×60mm
Weight 0.25KG (IP Camera Only); 0.4KG (with Packing Box)
S+265: Tiandy enhanced H.265 codec
ANR: Auto store video in SD card when NVR disconnected, and upload video to
NVR when resumed connection(Only Support Tiandy ANR NVR)
