Features

• Early Warning(EW)

• IR LED+White Light+Speaker

• Starlight Ultra Low Light 0.002lux

• H.265/H.264 HP/MP/BP/M-JPEG Codec

• Up to 1920×1080@30fps

• Mechanical WDR 140dB

• Min. Illumination Color: 0.002 Lux,B/W: 0.001 Lux, 0 Lux with IR

• VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Early warning/Crowd/Audio Abnormal Detection/Video Abnormal Detection

• Smart IR, IR Range: 50m

• Speed Max 60°/s, -2~90° Tilt Angle

• Optical Zoom: 4x, Digital Zoom: 16x

• Built-in Gyro and Support Image Auto-flip

• Interface Bulit-in Mic,Built-in Speaker,Audio in/out 1/1,Alarm in/out 2/1,MicroSD Card Slot, up to 128GB, Reset Button

• Support Wifi

• Operating Conditions -10°C-50°C, 0～95% RHG

• TVS 6000V, Lightning/Surge 4000V Protection, Indoor IP65

• CE, FCC

Specification

Camera
Image Sensor 1/2.8″ CMOS
Effective Pixels 1920(H)x1080(V)
Signal System PAL/NTSC
Minimum Illumination Color: 0.002Lux @(F1.6, 50 IRE，ICR off)
Black&White:0.001Lux @（F1.6,50 IRE，ICR ON）
0 lux with IR
White Balance Auto/ ATW/ Manual
AGC Auto/Manual
S/N Ratio ≥ 55dB
BLC Y
HLC Y
Smart Defog Y
WDR 140dB
Digital Noise Reduction 3D DNR
Exposure Mode Auto/ Manual
Shutter Time 1/1s～1/100000s
Day& Night IR Cut Filter with Auto Switch
Digital Zoom 16x
Privacy Masking 24 Privacy Mask Programmable; Optional Multiple Colors
Auto Focus Auto/ Semi-automatic/ Manual
OSD Size:16×16, 32×32, 24×24, 48×48, 64×64
Letters, Week, Date, Time, Total 5 Regions
PTZ Angle Superposition
S/N Ratio >60dB
Lens
Focal Length 2.8-12mm, 4x
Zoom Speed Approx.5s(Optical Wide-Tele)
Angle of View 104°(w)～30°(t)
Minimum Working Distance 0.5-1m(Wide-Tele)
Aperture Range F1.4-F2.8
Pan & Tilt
Pan Range 355° Endless
Pan Speed Pan Manual Speed: 0.1° -60°/s,
Pan Preset Speed: 60°/s
Preset Accurity ±0.2°
Tilt Range -2°-90° (Auto Flip )
Tilt Speed Tilt Manual Speed: 0.1°-60°/s,
Tilt Preset Speed: 60°/s
Proportional Zoom Rotation Speed Can Be Adjusted Automatically According to Zoom Multiples
3D Position Y
Number of Preset 500
Scan 8
Cruise 8, up to 32 Presets per Cruise
Pattern 8, Each One With 600s Memory or 300 Orders
Power loss recovery Y
Guard Action Preset/ Cruise/ Pattern/ Scan
PTZ Position Display Y
Freeze Frame Y
RS-485 Protocols DOME_PELCO_D，DOME_PELCO_P，DOME_PLUS
Infrared
IR Irradiation Distance 50m
IR Irradiation Angle Adjustable by Zoom
Interface
Audio Input 1-ch Mic in(Line in Interface)
Line Input 2-2.4V[p-p]; Output Impedance 1KΩ, ±10%
Audio Output Built-in Speaker
Line level, Impendance: 600Ω
Ethernet 1-ch RJ45 10M/ 100M
Alarm Input 2-ch
Alarm Output 1-ch
On-board Storage MicroSD Card Slot, up to 128GB
BNC&RS-485 Y
Extension N/A
Network
Ethernet 10Base -T/100Base-TX RJ45 Connector
Max.Image Resolution 1920×1080
Main Stream 1920×1080@25/30fps; 1280×960@25/30fps;
1280×720@25/30fps; 640×480@25/30fps;
704×576@25fps; 704×480@30fps
Sub Stream 704×576@25/30fps;704×480@25/30fps;
704×288@25/30fps;704×240@25/30fps;
352×240@25/30fps;352×288@25/30fps;
Third Stream 352×240@25/30fps;
352×288@25/30fps;
Image Compression H.265/H.264 High Profile/MJPEG
Audio Compression G711A/G711U/ADPCM/AAC
Protocols IPv4/IPv6/HTTP/802.1x/FTP/SMTP/UPnP/SNMP/DNS/DDNS
/NTP/RTSP/TCP/UDP/DHCP/PPPoE/HTTPS/ARP/RTP/QoS/MULITCAST/ICMP/IGMP
Remote Connection 5 Users Access at the Same Time
User Permission Up to 32 Users, 4 Levels
Security Measures User Authentication (ID and PW),
Host Authentication (MAC Address)
IP Address Filtering
Web Browser CHROME V45 or lower, IE, FIREFOX
System Compatibility ONVIF (Profile S), SDK
Advance
Early Warning(EW) When the target break into the area and trigger alarm, enable the speaker to warn, and flashing white light for frightening
Video Analytics Tripwire/Double Tripwire/Perimeter/Object Abandon/Object
Object Lost/Running/Loitering/Parking/Crowd
Audio Abnormal Detection/Video Abnormal Detection
Intelligent Alarm Harsh Voice Alarm, Motion Ddetection, Mask Alarm, Port Alarm
Network Disable Alarm, IP Conflict, MAC Conflict Detection
General
Language English,Spanish,Korean,Italian,Turkish,Thai,Russian,
Traditional Chinese,Simplified Chinese,Polish,French
Operating Conditions -10°C-50°C, 0～95% RHG
Power Supply DC12V/POE/AC24
Power Consumption 4.9W(IR OFF)/ 8.9W(IR ON )
Circuit Protection TVS 6000V, Lightning/ Surge 4000V Protection
Impact Protection Indoor IP65
IR LEDs 3pcs
Wiper N/A
Dimensions 152.2mmx141mmx141mm
Weight 0.8KG (IP PTZ Only), 1.2KG (with Packing Box)
S+265: Tiandy enhanced H.265 codec
ANR: Auto store video in SD card when NVR disconnected, and upload video to
NVR when resumed connection(Only Support Tiandy ANR NVR)
