Features
• Starlight Ultra Low Light 0.002lux
• H.265/H.264 HP/MP/BP/M-JPEG Codec
• Up to 1920×1080@30fps
• Mechanical WDR 140dB
• Optical Zoom: 33x, Digital Zoom: 16x
• Speed Max 550°/s, -15~90° Tilt Angle
• NIR, WDR, 3D DNR, HLC, Dual-ICR, AWB, AGC, BLC
• VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection
• Interface Audio in/out 1/1,Alarm in/out 1/1,MicroSD Card Slot, up to 128GB, Reset Button
• TVS 6000V, Lightning/Surge 4000V Protection, IP67
• Operating Conditions -40°C-70°C, 0～95% RHG
• CE, FCC
Specification
| Camera | |
| Image Sensor | 1/2.8″ CMOS |
| Effective Pixels | 1920X1080 |
| Signal System | PAL/NTSC |
| Minimum Illumination | Color: 0.002 Lux @(F1.6,AGC ON) |
| White Balance | Auto/ATW/Manual |
| AGC | Auto/Manual |
| S/N Ratio | ≥ 50dB |
| BLC | Y |
| HLC | Y |
| Smart Defog | Y |
| WDR | 140dB |
| Digital Noise Reduction | 3D DNR |
| Exposure Mode | Auto/Manual/Iris First/Shutter First |
| Shutter Time | 1s-1/100000s |
| Day& Night | IR Cut Filter with Auto Switch |
| Digital Zoom | 16X |
| Dynamic Privacy Masking | 24 Dynamic Privacy Masks Programmable; Optional Multiple Colors |
| Auto Focus | Auto/ Semi-automatic/ Manual |
| OSD | 16×16,32×32,24×24,48×48,64×64 Character Size Time, Date, Week, Character Superposition in 5 Regions PTZ Angle Superposition |
| Lens | |
| Focal Length | 4.6-152mm, 33x |
| Optical Zoom Speed | Approx.5s(Optical Wide-Tele) |
| Angle of View | 62.1°(w)～2.18°(t) |
| Minimum Working Distance | 1-1.5m(Wide-Tele) |
| Aperture Range | F1.6-F4.8 |
| Pan & Tilt | |
| Pan Range | 360° Endless |
| Pan Speed | Pan Manual Speed 0.1°～550°/s (Stepless Speed) |
| Pan Preset Speed 550°/s | |
| Preset Accurity | ±0.2° |
| Tilt Range | -15°~90°Auto Flip |
| Tilt Speed | Tilt Manual Speed 0.1°-550°/s |
| Tilt Preset Speed 550°/s | |
| Proportional Zoom | Rotation Speed Can Be Adjusted Automatically According to Zoom Multiples |
| 3D Position | Y |
| Number of Preset | 500 |
| Scan | 8 |
| Cruise | 8, Up to 32 Presets per Cruise |
| Pattern | 8, Each One With 600s Memory or 300 Orders |
| Power Loss Recovery | Y |
| Guard Action | Preset/ Cruise/ Pattern/ Scan |
| PTZ Position Display | Y |
| Freeze Frame | Y |
| Interface | |
| Audio Input | 1-ch Mic in(Line in Interface) Line Input 2-2.4V[p-p]; Output Impedance 1KΩ, ±10% |
| Audio Output | 1-ch Line Level |
| Ethernet | 1-ch RJ45 10M / 100M |
| Alarm Input | 1-ch |
| Alarm Output | 1-ch |
| On-board Storage | MicroSD Card Slot, up to 128GB |
| BNC&RS-485 | N/A |
| Extension | N/A |
| Network | |
| Ethernet | 10Base -T /100Base-TX RJ45 Connector |
| Max.Image Resolution | 1920×1080 |
| Main Stream | 1920×1080@25/30fps; 1280×960@25/30fps;1280×720@25/30fps; 1280×720@50/60fps; 704×576@25/50fps;704×480@30/60fps |
| Sub Stream | 704×576@25fps/704×480@30fps; 352×288@25fps/352×240@30fps; 176×144@25fps/176×120@30fps |
| Third Stream | 352×288@25fps/352×240@30fps |
| Image Compression | H.265/H.264 HP/MP/BP/M-JPEG |
| ROI Encoding | 8 Dynamic Areas for Both Main and Sub Stream |
| Audio Compression | G.711A/G.711U/AAC/ADPCM |
| Protocols | IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE |
| Remote Connection | 5 Users Access at the Same Time |
| User/Host Level | Up to 32 Users, 4 Levels |
| Security Measures | User Authentication (ID and PW), |
| Host Authentication (MAC Address) | |
| IP Address Filtering | |
| Web Browser | IE8,IE9,IE10,IE11,Firefox24 |
| System Compatibility | ONVIF (Profile S), SDK |
| Advance | |
| Video Analytic(VCA) | Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection |
| Intelligent Alarm | Motion Ddetection, Mask Alarm, Port Alarm,Network Disable Alarm, IP Conflict, MAC Conflict Detection |
| General | |
| Language | English,Spanish,Korean,Italian,Turkish,Thai,Russian,Traditional Chinese,Simplified Chinese,Polish,French |
| Operating Conditions | -40°C-70°C, 0～95% RHG |
| Power Supply | AC24V 2A Independent External Power Adapter |
| Power Consumption | 16W/18W(ICR Instant Switch) |
| Circuit Protection | TVS 6000V, Lightning/ Surge 4000V Protection |
| Impact Protection | IP67 |
| Dimensions | 298mm×216mm×216mm |
| Weight | 3.7KG (IP PTZ Only), 6KG (With Packing Box) |
