Features

• Autotracking Early Warning(AEW)

• IR LED+White Light+Green Laser

• Starlight Ultra Low Light 0.002lux

• H.265/H.264 HP/MP/BP/M-JPEG Codec

• Up to 1920×1080@60fps

• Mechanical WDR 140dB

• Smart IR, IR Range: 200m

• Min. Illumination Color: 0.002 Lux,B/W: 0.001 Lux, 0 Lux with IR

• NIR, WDR, 3D DNR, HLC, Dual-ICR, AWB, AGC, BLC

• VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Early Warning/Crowd/Audio Abnormal Detection/Video Abnormal Detection/Face Detection/People Counting/On duty Detection/Auto tracking

• Optical Zoom: 33x, Digital Zoom: 16x

• Speed Max 400°/s, -16~90° Tilt Angle

• Interface Built-in Speaker,Audio in/out 1/1,Alarm in/out 8/2,MicroSD Card Slot, up to 128GB, Reset Button,RS-485,BNC

• TVS 6000V, Lightning/Surge 4000V Protection, IP66

• Operating Conditions -40°C-70°C, 0~95% RHG

• CE, FCC

Specification

Camera
Image Sensor 1/2.8″ CMOS
Effective Pixels 1920(H)x1080(V)
Signal System PAL/NTSC
Minimum Illumination Color: 0.002 Lux @(F1.6,AGC ON)
Black&White:0.001Lux @(F1.6,AGC ON)
0 Lux with IR
White Balance Auto/ ATW/ Manual
AGC Auto/ Manual
S/N Ratio ≥ 55dB
BLC Y
HLC Y
Smart Defog Y
WDR 140dB
Digital Noise Reduction 3D DNR
Exposure Mode Auto/ Manual/ Iris First/ Shutter First
Shutter Time 1/1s-1/100000s
Day& Night Dual-ICR
Digital Zoom 16x
Privacy Masking 24 Dynamic Privacy Mask Programmable; Optional Multiple Colors
Auto Focus Auto/ Semi-automatic/ Manual
OSD 16×16,32×32,24×24,48×48,64×64 Character Size
Time/Date/Week/Character Superposition in 5 Regions
PTZ Angle Superposition
Lens
Focal Length 4.6-152mm, 33x
Zoom Speed Approx.5s(Optical Wide-Tele)
Angle of View 62.1°(w)~2.18°(t)
Minimum Working Distance 1-1.5m(Wide-Tele)
Aperture Range F1.6 ~ F4.8
Pan & Tilt
Pan Range 360°endless
Pan Speed Pan Manual Speed: 0.1° -400°/s
Pan Preset Speed: 240°/s stepless
Preset Accurity ±0.2°
Tilt Range -16°-90° (Auto Flip )
Tilt Speed Tilt Manual Speed: 0.1°-400°/s
Tilt Preset Speed: 240°/s
Proportional Zoom Rotation Speed Can Be Adjusted Automatically According to Zoom Multiples
3D Position Y
Number of Preset 500
Scan 8
Cruise 8, up to 32 Presets per Cruise
Pattern 8, Each One With 600s Memory or 300 Orders
Power loss recovery Y
Guard Action Preset/ Cruise/ Pattern/ Scan
PTZ Position Display Y
Freeze Frame Y
RS-485 Protocols PTZ_PELCO_D,PTZ_PELCO_P,PTZ_TC615_P,DOME_PELCO_D,DOME_PELCO_P,DOME_PLUS
Infrared
IR Irradiation Distance 200m
IR Irradiation Angle Adjustable by Zoom
Interface
Audio Input 1-ch Mic in(Line in Interface)
Line Input 2-2.4V[p-p]; Output Impedance 1KΩ, ±10%
Audio Output Built-in Speaker
Line level, Impendance: 600Ω
Enthernet 1-ch RJ45 10M/ 100M
Alarm Input 8-ch
Alarm Output 2-ch
On-board Storage MicroSD Card Slot, up to 128GB
BNC 1.0Vp-p / 75Ω, NTSC (or PAL) Composite
RS-485 1-ch
Extension N/A
Network
Ethernet 10Base -T/100Base-TX RJ45 Connector
Max.Image Resolution 1920×1080
Main Stream 1920×1080@25/30fps;1920×1080@50/60fps;
1280×960@25/30fps;1280×960@50/60fps;
1280×720@25/30fps;1280×720@50/60fps
640×480@25/30fps;640×480@50/60fps
704×576@25/30fps;704×576@50/60fps
704×480@25/30fps;704×480@50/60fps
Sub Stream 704×576@25/30fps;704×480@25/30fps;
704×288@25/30fps;704×240@25/30fps;
352×240@25/30fps;352×288@25/30fps;
Third Stream 1280×720@25/30fps;640×480@25/30fps;704×576@25/30fps;
704×480@25/30fps;704×576@25/30fps;704×480@25/30fps;
704×288@25/30fps;704×240@25/30fps;352×240@25/30fps;
352×288@25/30fps;
Image Compression H.265/H.264, Encoding with Baseline/Main/High Profile
ROI Encoding 8 Dynamic Areas for Both Main and Sub Stream
Audio Compression G711A/G711U/ADPCM/AAC
Protocols IPv4/IPv6/ HTTP/ HTTPS/ 802.1x/ Qos/ FTP/ SMTP/ UPnP/ SNMP/ DNS/ DDNS/ NTP/ RTSP/ RTP/ TCP/ UDP/ IGMP/ ICMP/ DHCP/ PPPoE
Remote Connection 10 Users Access at the Same Time
User Permission Up to 32 Users, 4 Levels
Security Measures User Authentication (ID and PW),
Host Authentication (MAC Address)
IP Address Filtering
Web Browser IE8,IE9,IE10,IE11,Firefox24
System Compatibility ONVIF (Profile S), SDK
Advance
Autotracking Early Warning(AEW) Keep tracking the target that actives alarming, and enable the speaker to warn, even open the green laser for frightening
Video Analytics(IVA) Tripwire/Double Tripwire/Perimeter/Object Abandon/Object
Lost/Running/Loitering/Parking/Early Warning/Crowd/Audio Abnormal Detection/Video Abnormal Detection/Face Detection/People Counting/On duty Detection/Auto tracking
Smart-tracking By Manual/ Panorama/Tripwire/ Perimeter/Early warning trigger
Intelligent Alarm Harsh Voice Alarm, Motion Ddetection, Mask Alarm, Port Alarm,Network Disable Alarm, IP Conflict, MAC Conflict Detection
General
Language English,Spanish,Korean,Italian,Turkish,Thai,Russian,Traditional Chinese,Simplified Chinese,Polish,French
Operating Conditions -40°C-70°C, 0~95% RHG
Power Supply AC24V 3A
Power Consumption 18.6W(IR OFF)/ 35.5W(IR ON )
Circuit Protection TVS 6000V, Lightning/ Surge 4000V Protection
Impact Protection IP66
Wiper Y
IR LEDs 8pcs
White Light LEDs 2pcs
Dimensions 372mmx222mmx222mm
Weight 5.3KG (IP PTZ Only), 8.75KG (with Packing Box)
