Features

• 20-ch 4K/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF IP Camera Input

• 4-ch 4K/16-ch 1080P/20-ch 720P/4CIF Realtime Display

• 20-ch Sub-stream 4CIF Realtime Display

• 4-ch 4K/16-ch 1080P/720P/4CIF Sync Playback

• Up to 4K Resolution Recording

• Bandwidth in/out 400Mbps/200Mbps

• HDD Quota and Group Management

• Dual Gigabit Network Interfaces

• Support 20-ch Intelligent Analysis Process

• Smart Search&Recording, Plug&Play

• Support ANR Funtion

• Support N+M Hot Standby Function

• 1x HDMI, 1x VGA, Same Video Source, Max Resolution 4K

• 2 SATA(Up to 8TB), Alarm I/O 0/1,Audio I/O 1/1, 2x USB

• CE, FCC

Specification

Video/Audio Input
IP video input 20-ch
Two-way Audio Input 1-ch 3.5mm
Network
Incoming Bandwidth 400Mbps
Outgoing Bandwidth 200Mbps
Remote Connection 32 Users, Up to 160ch Videos
Browser IE8,IE9,IE10,IE11,Firefox24
Mobile Software P2P&DDNS for IOS&Android (Tiandy: Easylive, Neutral: Mobilelive)
Internet Protocol TCP/UDP/HTTP/MULTICAST/UPnP/DHCP/PPPoE/DDNS/NFS/FTP/NTP/HTTPS/RTSP/SMTP/HTTPS/SADP
Email Activated by Alarm
ANR Y, Auto download video from camera SD card, Which was stored when disconnnection (Only Support Tiandy ANR IP Camera)
Advanced Remaining Bandwidth Display
Video/Audio Output
HDMI Output 1-ch Resolution:3840×2160,2560×1600，2560×1440，1920×1080，1280×720，
800×600,1024×768,1366×768,1440×900,1280×800
VGA Output 1-ch Resolution: 1920×1080，1280×720，800×600,1024×768，1366×768,1440×900,1280×800 Adjustable Output mode, Self-adaptive Resolution
Frame Rate Mainstream 25fps(P)/30fps(N) Substream 25fps(P)/30fps(N)
I-Frame Record Y
Recording Resolution 4K(3840*2160,3264*2448,3296*2472)/6MP(2752*2208,3008*2008,2408*2008)/5MP(2560*1920,2592*1944,2592*1920,2528*2128/4MP(2560*1440,2592*1520)/3MP(2048*1536)/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Audio Output 1-ch 3.5mm
Synchronous Playback 4-ch 4K/16-ch 1080P/720P/4CIF
Decoding
Live View/Playback 4K(3840*2160,3264*2448,3296*2472)/6MP(2752*2208,3008*2008,2408*2008)/5MP(2560*1920,2592*1944,2592*1920,2528*2128/4MP(2560*1440,2592*1520)/3MP(2048*1536)/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability 4-ch 4K/16-ch 1080P/20-ch 720P/4CIF
Display Split 1/4/6/8/9/10/16/20/25
E-Zoom Y
Hard Disk
SATA 2 SATA for 2 HDDs
Capacity Up to 8TB Capacity for Each HDD
NTFS Files System Y
HDD Management Group and Quota, Customized Recording Days
External Interface
Network Interface 1X RJ-45 10/100/1000Mbps Self-adaptive Ethernet Interfaces
Serial Interface 1X RS-485, 1X RS-232
USB Interface 1x USB3.0, 1x USB2.0
Alarm In/Out 0/1
Advance
NAS NFS Protocol, Support Manual Backup Only
Plug and Play Y, Only for Tiandy Cameras
Image Flip Y, Only for Tiandy Cameras
Hot Standby N+M
Corridor Mode Y, 16:9 to 9:16, Only for Tiandy Cameras
Video Analytics(VCA) Support 20-ch Camera VCA Function,Including Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Early Warning/Crowd/Face Detection/People Counting/Audio Abnormal Detection/Video Abnormal Detection/On duty Detection
Smart Search Quickly Search Target Videos according to Channel No., Records Type, Records Time, File Type and VCA( Only for Tiandy Cameras )
Trigger Recording Manual/Timing/Motion Detection/Port Alarm/ VCA Alarm/Video Occlusion
Smart Recording Set Recording Bite Rate for Different Time
Alarm Recording Pre Alarm Default 10s (5/10/15/60s Optional) , Post Alarm Default 10s (10/15/30/60/600s Optional ).
One Key Control Intercom, Recording
Records Format SDV, Export MP4 in H.264 Format
Records Encryption Y
Records Tag Y
Onvif Onvif(Profile S)
General
Languge English, Spanish, Korean, Italian,Turkish,Thai, Russian, Traditional Chinese,Simplified Chinese, French, Polish
Power Supply DC12V 5A
Consumption(without HDD) ≤ 35W
Working Temperature -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)
Working Humidity 10 % ~ 90 %
Chassis 19” Rack Mount 1U Chassis, without Ear Boards, Need Order Extra
Dimensions 49mm×440mm×277mm
Weight 2.3KG (without HDD), 4KG (with Packing Box)
